牌号简介 About |
---|
DSM的Somos® GP Plus 14122是一种低粘度的液体光聚合物,能够生产防水、耐用和精确的三维零件。Somos® GP Plus 14122具有白色不透明外观,其性能反映了生产塑料,如ABS和PBT。应用Somos® GP Plus 14122非常适合汽车、航空航天和消费品行业的许多应用。Somos® GP Plus 14122成功地创建了功能原型、防潮/防水概念模型和耐用的小批量生产零件。 DSM's Somos® GP Plus 14122 is a low-viscosity liquid photopolymer that produces water-resistant, durable and accurate three-dimensional parts. Somos® GP Plus 14122 has a white, opaque appearance with performance that mirrors production plastics like ABS and PBT. Applications Somos® GP Plus 14122 is ideal for many applications in the automotive, aerospace and consumer product industries. Somos® GP Plus 14122 is successful in creating functional prototypes, humidity / water-resistant concept models, and durable low volume production parts. |
技术参数 Technical Data | |||
---|---|---|---|
物理性能 PHYSICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
密度 Density |
1.16 | g/cm³ | |
吸水率 Water Absorption |
|||
平衡 balance |
0.40 | % | ASTM D570 |
粘度 viscosity |
|||
30℃ 30℃ |
0.34 | Pa·s | |
冲击性能 IMPACT |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
悬臂梁缺口冲击强度 Izod Notched Impact strength |
23 到 29 | J/m | ASTM D256-A |
热性能 THERMAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
热变形温度 HDT |
ASTM D648 | ||
0.45 MPa,未退火 0.45 MPa, unannealed |
46.0 | ℃ | ASTM D648 |
1.8 MPa,未退火 1.8 MPa, unannealed |
℃ | ASTM D648 | |
玻璃化转变温度 Glass transition temperature |
℃ | ASTM E1545 | |
线性热膨胀系数 Coeff.of linear therm expansion |
|||
MD MD |
ASTM E831 | ||
-40 到 0℃ -40 to 0 ℃ |
cm/cm/℃ | ASTM E831 | |
0 到 50℃ 0 to 50 ℃ |
cm/cm/℃ | ASTM E831 | |
50 到 100℃ 50 to 100 ℃ |
cm/cm/℃ | ASTM E831 | |
100 到 150℃ 100 to 150 ℃ |
cm/cm/℃ | ASTM E831 | |
电气性能 ELECTRICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
介电强度 Dielectric strength |
kV/mm | ASTM D149 | |
介电常数 Dielectric constant |
ASTM D150 | ||
60 Hz 60 Hz |
ASTM D150 | ||
1 kHz 1 kHz |
ASTM D150 | ||
1 MHz 1 MHz |
ASTM D150 | ||
补充信息 Supplementary information |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
Critical Exposure Critical Exposure |
mJ/cm² | ||
渗透深度 Penetration depth |
µm | ||
穿刺能量 Puncture energy |
|||
High Speed PunctureImpact High Speed PunctureImpact |
J | ASTM D3763 | |
机械性能 MECHANICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
邵氏硬度 Shore hardness |
|||
邵氏 D Shaw's D |
ASTM D2240 | ||
拉伸模量 Tensile modulus |
MPa | ASTM D638 | |
拉伸强度 tensile strength |
ASTM D638 | ||
屈服 yield |
MPa | ASTM D638 | |
断裂 fracture |
MPa | ASTM D638 | |
拉伸应变 Tensile strain |
ASTM D638 | ||
屈服 yield |
% | ASTM D638 | |
断裂 fracture |
% | ASTM D638 | |
弯曲模量 Flexural Modulus |
MPa | ASTM D790 | |
弯曲强度 Flexural Strength |
MPa | ASTM D790 | |
泊松比 Poisson's ratio |
ASTM D638 |
备注 |
---|
1 一般属性:这些不能被视为规格。 |
